Technical specifications:
| Unit | OWD-1000A | |
|---|---|---|
| Permissible loading of working table |
N |
10 000 |
| Max. casting (load) dimensions |
mm |
dia. 1200x1100 |
| Number of projecting rotors |
pcs. |
2 |
| Rotor capacity |
kg/min |
150 |
| Recommended shot granulation |
min |
0,5 - 2,5 |
| Approximate shot blasting time of a load of castings considering their rearrangement on the table | ||
| - iron castings |
min |
3 - 6 |
| - steel castings |
min |
6 - 12 |
| Compressed air consumption for 8h operation |
m3 |
0,2 |
| Working air pressure |
MPa |
0,4 - 0,6 |
| Total installed power |
kW |
24,1 |
| Required capacity of dust extraction equipment |
m3/min |
1,66 |
| Required vacuum at connection pipe |
Pa |
550 |
